Cranial Bur Model OTS-9
Original price was: $1,027.00.$949.00Current price is: $949.00.
– Powerful and precise cranial bur for neurosurgery
– Swiss-made motor for reliability
– Variable speed control without steps for stability
– Sterilizable main unit for hygiene
– High output power of ≥70W
Description
Cranial Bur Model OTS-9
Powerful and precise cranial bur engineered for neurosurgical applications. Swiss-made motor delivers ≥70W output with variable speed control for superior stability and control. Sterilizable main unit supports high-temperature protocols up to 135°C.
Clinical overview
The Cranial Bur Model OTS-9 is a precision-engineered neurosurgical instrument designed for demanding cranial procedures. Featuring a Swiss-made motor, this cordless system delivers consistent, high-output power (≥70W) with stepless variable speed control from 0–50,000 RPM, enabling surgeons to optimize performance across diverse bone densities and surgical techniques. The sterilizable main unit supports high-temperature protocols up to 135°C, ensuring compliance with institutional sterilization standards and reducing cross-contamination risk.
The system combines portability with reliability, featuring a 14.4V lithium battery with ≥1 hour runtime and rapid 30-minute charging. Low noise operation (≤70 dB) minimizes OR fatigue, while the ergonomic design supports extended operative time. Ideal for craniotomies, burr holes, and complex neurosurgical access procedures.
Key features & surgeon benefits
High-Output Swiss Motor
- ≥70W output power for efficient bone removal
- 0–50,000 RPM stepless variable speed control
- ±20% speed stability for precision work
- Swiss-engineered reliability and durability
Cordless Convenience
- 14.4V lithium battery with ≥1 hour capacity
- 30-minute rapid charging cycle
- Portable, untethered operation in the OR
- Low noise ≤70 dB for reduced OR fatigue
Infection Control Ready
- Main unit sterilizable up to 135°C high-pressure steam
- Battery remains non-sterilizable for longevity
- Supports institutional sterilization protocols
- Reduces cross-contamination risk
Flexible Configuration
- OEM and custom configurations available
- Adaptable to institutional requirements
- Volume pricing for multi-unit orders
- Technical support and training included
Technical specifications
| Indications | Neurosurgery, craniotomy, burr holes, cranial access procedures |
|---|---|
| Sizes / range | 0–50,000 RPM (variable speed control, ±20%) |
| Material | Surgical-grade steel and composite housing |
| Sterilisation | Main unit: high-temperature steam up to 135°C; Battery: non-sterilizable |
| Packaging | Carrying case with charger and battery |
| Warranty | As applicable — contact sales for details |
Motor & power specifications
| Parameter | Specification |
|---|---|
| Motor working voltage | 14.4V DC |
| Output power | ≥70W |
| Speed range | 0–50,000 RPM (stepless variable control) |
| Speed stability | ±20% |
| Noise level | ≤70 dB |
| Battery voltage | 14.4V lithium |
| Battery capacity | ≥1 hour runtime |
| Charging time | 30 minutes |
| Charger input | AC 110V–240V, 50Hz |
| Charger output | 14.4V DC |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Motor unit | Sterilizable main unit with ergonomic grip | 1 |
| Battery pack | 14.4V lithium battery, ≥1 hour capacity | 1 |
| Charger | AC 110V–240V input, 30-minute rapid charge | 1 |
| Carrying case | Protective transport and storage case | 1 |
Get in touch for pricing & availability
Contact our sales team to request a quote, discuss customization options, or arrange a clinical demonstration of the Cranial Bur Model OTS-9.
