BJ1403B Dual canulate drill (System 1400)
- Autoclavable canulate drill for intramedullary interlocking nail or arthroscopic surgery
- Imported motor with low noise and high speed
- Warranty for 1 year
- Can connect various flexible reamers for quick surgery process
- SKU
- 8246E8FC3FBF
- Brand
- Teds Medical
- Availability
- In stock
- ✓ Worldwide shipping
BJ1403B Dual Cannulated Drill
High-performance autoclavable cannulated drill system designed for intramedullary interlocking nail procedures and arthroscopic surgery. Features imported motor technology with exceptional speed control, low noise operation, and ergonomic design for extended surgical use. Compatible with K-wires and flexible reamers for versatile intraoperative applications.
Clinical overview
The BJ1403B Dual Cannulated Drill represents a significant advancement in powered surgical instrumentation for trauma and arthroscopic procedures. Engineered with an imported motor system, this drill delivers precise speed control from 0 to 630 rpm with exceptional torque characteristics (3.3 Nm), making it ideal for intramedullary nail insertion, K-wire placement, and flexible reaming applications. The ergonomic handpiece design reduces surgeon fatigue during extended procedures while maintaining optimal control and alignment.
The system's fully autoclavable handpiece (sterilizable up to 135°C at 1.6 MPa) ensures comprehensive infection control without compromising instrument longevity. Operating at remarkably low noise levels (≤40 dB), the BJ1403B minimizes acoustic stress in the operating theatre. The environmentally responsible nickel-metal hydride battery system provides reliable power delivery with a convenient aseptic transfer ring for sterile field integration. Quick-change compatibility with various flexible reamers streamlines workflow and reduces instrument exchange time during complex procedures.
Key features & surgeon benefits
Precision motor technology
- Variable speed control 0–630 rpm for optimal drilling precision
- High torque output (3.3 Nm) for efficient bone penetration
- Imported motor with superior alignment and extended service life
- Low noise operation (≤40 dB) reduces theatre acoustic stress
Surgical efficiency
- Quick-connect system for flexible reamers and drill attachments
- Ergonomic handpiece design minimizes surgeon fatigue
- Aseptic battery transfer ring enables sterile field integration
- Cannulated design accommodates K-wires for guided drilling
Infection control excellence
- Fully autoclavable handpiece up to 135°C (1.6 MPa)
- High-temperature sterilisation eliminates resistant pathogens
- Durable construction withstands repeated autoclave cycles
- Comprehensive sterilisation protocol included in documentation
Long-term value
- 1-year warranty on handpiece demonstrates quality assurance
- Environmentally responsible NiMH battery technology
- Modular System 1400 platform enables instrument expansion
- Reduced maintenance costs through robust motor design
Technical specifications
| Indications | Intramedullary interlocking nail surgery, arthroscopic procedures, K-wire placement and guided drilling |
|---|---|
| Output power | 85 W |
| Speed range | 0–630 rpm (variable control) |
| Torque | 3.3 Nm |
| Operating voltage | 9.6 V (NiMH battery) |
| Noise level | ≤40 dB |
| Sterilisation | Autoclavable up to 135°C at 1.6 MPa (handpiece only; battery not autoclavable) |
| Material | Medical-grade stainless steel |
| Packaging | Complete system with protective case |
| Warranty | 1 year on handpiece; 3 months on battery and consumable components |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Handpiece | BJ1403B cannulated drill handpiece (autoclavable) | 1 |
| Battery | 9.6V NiMH rechargeable battery pack | 1 |
| Charger | Battery charging unit with power adapter | 1 |
| Chuck | Quick-release drill chuck for bit attachment | 1 |
| Aseptic transfer ring | Sterile battery transfer device for OR use | 1 |
| Operating manual | Comprehensive user and maintenance guide | 1 |
| Guarantee card | Warranty documentation and registration | 1 |
Important usage notes
Sterilisation protocol
- Maximum sterilisation temperature: 135°C (exceeding may damage motor)
- Ensure battery compartment is completely dry post-sterilisation
- Battery must never be autoclaved — use aseptic transfer ring only
- Clean and dry all components immediately after surgery
Battery management
- Remove battery from handpiece immediately after surgery
- Leaving battery installed causes self-discharge and reduced lifespan
- Use environmentally responsible NiMH battery technology
- Battery warranty: 3 months under normal usage conditions
Drill bit compatibility
- Standard configuration holds drill bits up to 6 mm diameter
- Cannulated design accommodates K-wires for guided procedures
- Compatible with various flexible reamers via quick-connect system
- Optimal speed ~600 rpm for cannulated nail/wire applications
Maintenance recommendations
- Clean instruments immediately post-surgery to prevent blood adhesion
- Use purger system for thorough cleaning of cannulated components
- Ensure complete drying before sterilisation cycle
- Inspect motor alignment and chuck function regularly
Get in touch for pricing & availability
Contact our surgical instruments team for detailed pricing, technical specifications, and information on System 1400 platform compatibility. We provide comprehensive support for instrument selection, sterilisation protocols, and clinical applications.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
Customer reviews
No reviews yet — be the first to share your experience.
