Ankle Joint External Fixator
- Includes rod-rod coupling, rod-pin coupling, ankle joint, apex pins
- Designed for ankle joint external fixation
- Easy to order and fast delivery in 7 days
- Perfect quality for orthopedic surgeons and patients
- SKU
- 7100-19
- Brand
- Teds Medical
- Availability
- In stock
- ✓ Worldwide shipping
Ankle Joint External Fixator
A comprehensive ankle joint external fixation system designed for complex ankle trauma, fracture stabilization, and joint distraction procedures. This complete set integrates articulated joint mechanics with robust rod-pin coupling architecture, enabling controlled motion while maintaining anatomical alignment during healing. Engineered for rapid deployment and reliable performance in acute trauma and reconstructive applications.
Clinical overview
The Ankle Joint External Fixator represents a proven Hoffman-type solution for managing complex ankle pathology requiring temporary or definitive external stabilization. The system's articulated ankle joint component permits controlled dorsiflexion and plantarflexion during the healing process, facilitating early mobilization protocols while maintaining fracture reduction and joint alignment. This approach reduces stiffness, preserves soft tissue integrity, and supports accelerated functional recovery in challenging cases including high-energy pilon fractures, open injuries, and severe ligamentous disruptions.
Designed with surgical efficiency in mind, the complete set arrives ready for immediate deployment with all necessary couplings, pins, and joint mechanisms. The 8mm rod architecture provides robust mechanical stability while the self-drilling apex pins streamline insertion technique. Surgeons benefit from a time-tested external fixation platform that balances structural rigidity with the flexibility to accommodate patient-specific anatomy and evolving treatment strategies during the post-operative period.
Key features & surgeon benefits
Comprehensive Ankle Stabilization
- Articulated ankle joint enables controlled motion during healing
- Suitable for pilon fractures, open injuries, and joint distraction procedures
- Accommodates complex fracture patterns and soft tissue compromise
- Supports both temporary and definitive fixation strategies
Streamlined Surgical Technique
- Complete set eliminates component selection and assembly delays
- Self-drilling apex pins reduce insertion steps and operative time
- Intuitive rod-pin and rod-rod coupling system for rapid frame construction
- Proven Hoffman-type design familiar to trauma surgeons worldwide
Value-Driven Solution
- All-inclusive set pricing simplifies procurement and budgeting
- 7-day delivery ensures availability for urgent trauma cases
- Reusable components reduce per-case costs in high-volume centers
- Minimizes inventory complexity with standardized configuration
Adaptable Platform
- Multiple pin diameters (3mm, 5mm) for anatomical versatility
- 8mm rod system compatible with additional Hoffman-type components
- Custom pin lengths and rod configurations available on request
- Modular architecture supports frame adjustments and revisions
Technical specifications
| Indications | Ankle fractures, pilon fractures, joint distraction, ligamentous instability, post-traumatic reconstruction, open injuries requiring staged management |
|---|---|
| Sizes / range | 8mm rod system; 3mm × 120mm and 5mm × 150mm self-drilling apex pins |
| Material | Medical-grade stainless steel (rods, couplings, joint, pins) |
| Sterilisation | Steam autoclave (134°C, 18 minutes minimum) |
| Packaging | Complete set in protective case; individual components labeled |
| Warranty | As per manufacturer's standard terms; defect-free guarantee |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| 7100-1901 | Rod-Rod Coupling (8mm Rod) | 1 |
| 7100-1902 | Rod-Pin Coupling (5/6mm Pin, 8mm Rod) | 4 |
| 7100-1903 | Ankle Joint 8mm | 1 |
| 7100-1906 | Apex Pin Self-drilling 5×150mm | 4 |
| 7100-1907 | Apex Pin Self-drilling 3×120mm | 1 |
Get in touch for pricing & availability
Our team is ready to provide detailed quotations, technical documentation, and delivery timelines. Fast 7-day delivery available for urgent trauma cases.
Email: [email protected]
Available on request
Configuration, paperwork & clinical fit
The full spec + documentation pack for this device ships ahead of purchase on request. A sales engineer responds within one business day.
Configuration sheet
Specifications, accessories & clinical fit
Sizes and dimensions, material and finish, compatible instruments and screw references, what ships in the set, lead time and warranty — all in one specification sheet, sent within one business day.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
Customer reviews
No reviews yet — be the first to share your experience.
Related products
See all →
Femoral External Fixator
- Complete femoral external fixator kit - Includes tube-rod coupling, compression distraction tube, pin clamp, angled post, and self-drilling apex pins - Easy ordering for patients and orthopedic surgeons - High-quality materials for effective fixation - Quick delivery within 7 days
Femoral External Fixator
- Includes tube-rod coupling, compression distraction tube, 5-hole pin clamp, and angled post - Comes with a total of 11 essential components - High-quality product for orthopedic procedures - Easy ordering process with quick 7-day delivery time
Knee Joint External Fixator
- Includes rod-rod and rod-pin couplings for flexibility in fixation - Features a knee joint component for stability - Comes with a 5-hole pin clamp for secure attachment - Includes a 30-degree angled post for customized positioning - Easy to order and receive in just 7 days - Perfect quality recommended by experts for orthopedic surgeries
Ankle Joint External Fixator
- The Ankle Joint External Fixator includes Rod-Rod Coupling, Rod-Pin Coupling, Aluminum Connecting Rods, and Apex Pin - Quality is top-notch for ease of use by patients and orthopedic surgeons - Comes with instruments, accessories, and application parts - Orders delivered promptly within 7 days
Pelvic External Fixator
- Complete set for pelvic external fixation - Includes rod-rod coupling, pin clamp, angled post, and connecting rods - Also comes with self-drilling apex pins - High-quality materials for optimal performance
Proximal Femur External Fixator
- Complete external fixator set for proximal femur fractures - Includes rod-rod couplings, pin clamps, angled posts, connecting rods, and self-drilling apex pins - Designed for stabilizing and aligning fractures of the proximal femur - Made of high-quality materials for durability and reliability
Tibia & Percone External Fixator
