Cardios Pro Stress Test System
Original price was: $3,874.00.$3,224.00Current price is: $3,224.00.
– Cardios Pro Stress Test System for evaluation of exercise stress test including ECG, symptoms, and blood pressure
– Features high-resolution A/D conversion and patented Meditech technology for accurate measurements
– Offers different selectable filters, arrhythmia detection, and live review for comprehensive analysis
– Compatible with various treadmills and ergometers, with preset protocols and user-defined options
– Includes exercise testing hardware, software for real-time analysis, and data management capabilities
Description
Cardios Pro Stress Test System
Comprehensive exercise stress testing platform with high-resolution ECG acquisition, real-time ST analysis, and integrated blood pressure monitoring. Delivers accurate cardiac evaluation through patented Meditech technology and synchronized multi-channel A/D conversion for clinical confidence.
Clinical overview
The Cardios Pro Stress Test System provides clinicians with a robust platform for comprehensive exercise stress testing, combining high-resolution ECG acquisition with real-time hemodynamic monitoring. The system evaluates cardiac response to graded exercise through synchronized ECG, blood pressure, oxygen saturation, and metabolic parameters, enabling accurate detection of exercise-induced ischemia and arrhythmias.
Patented Meditech technology—including digital synchronous A/D conversion and myoelectric filtering—ensures signal fidelity and artifact rejection. Preset classical protocols and unlimited user-defined options support diverse testing methodologies, while rehabilitation mode facilitates cardiac function recovery assessment. Compatible with major treadmill and ergometer platforms, the system integrates seamlessly into existing laboratory workflows.
Key features & surgeon benefits
Precision ECG Acquisition
- 24-bit A/D conversion at 24 kSPS per channel
- 0.4 μV resolution with >110 dB common-mode rejection
- Patented minimum-delay baseline wander eraser
- Soft anti-aliased ECG display for clinical clarity
Integrated Real-Time Analysis
- Real-time average complexes and continuous ST analysis
- Arrhythmia detection with live review capability
- Synchronized ECG, BP, SpO₂, METS, VO₂ display
- Re-analysis of complete test with ST and HR trends
Protocol & Equipment Compatibility
- Preset classical protocols plus unlimited user-defined options
- Independent testing for treadmills and ergometers
- Compatible with COSMOS, TrackMaster, ERGOSANA systems
- Automatic ergometer control via RS-232 interface
Comprehensive Reporting
- 12-lead resting ECG with simultaneous acquisition
- Trend tracking and comparative analysis tools
- Rehabilitation mode for cardiac recovery protocols
- Full data archiving and export capabilities
Technical specifications
| Indications | Exercise stress testing, cardiac function evaluation, arrhythmia detection, rehabilitation monitoring |
|---|---|
| Sampling rate (A/D) | 24 kSPS per channel; recording 1 kSPS per channel |
| Quantization precision | A/D: 24 bits; Recording: 16 bits |
| Resolution | 0.4 μV |
| Common-mode rejection | >110 dB |
| Input impedance | >20 MΩ |
| Frequency response | 0.05–250 Hz (±3 dB) |
| Time constant | ≥3.2 seconds |
| Dynamic range | ±25 mV |
| Maximum electrode potential | ±800 mV DC |
| Defibrillation protection | Built-in |
| Patient current leakage | <10 μA |
| Communication | Isolated USB (4000 V) |
| Treadmill compatibility | Speed 0–20 km/h (0.1 km/h steps); elevation 0–22% (0.1% steps); weight capacity 200 kg |
| Sterilisation | As applicable |
| Warranty | As applicable |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| ECG Patient Cable | 10-lead, 3.5 m length | 1 |
| Disposable Exercise ECG Electrodes | Standard electrodes for stress testing | 25 |
| Chest Electrodes | Precordial placement | 6 |
| Clamp Electrodes | Limb lead attachment | 4 |
| Cleaning Cloth | Electrode site preparation | 1 |
| Digital ECG Acquisition Box | Cardios Pro hardware unit | 1 |
| Exercise ECG Software | Real-time analysis and data management | 1 |
| Resting ECG Software | 12-lead simultaneous acquisition | 1 |
Get in touch for pricing & availability
Contact our sales team to discuss system configuration, integration requirements, and volume pricing for the Cardios Pro Stress Test System.
Email: info@tedsmedical.com
